Dual-mode Gas Storage Cabinet

Brand: Wanze Shengshi

Color: Customized
Material: Carbon Steel/Stainless Steel
MOQ: 1
Sales Models: Customized
Specification: Customized

Availability:



Inquire

Product Description

The gas cabinet comes with a set of overpressure protection devices to prevent overpressure in the gas cabinet in an emergency. Antifreeze can be added to the water seal to meet the needs of severe cold conditions. Stainless steel guide rails and Hilti expansion bolts are used for on-site positioning and installation without pre-embedding, which is conducive to civil construction and installation is quick and fast.

Design Parameters

*Biogas storage capacity: 20-8000m³

*Design storage pressure: 10-35mbar

*Design snow load: 0-150kg/m²

*Design wind load: 0-150km/h

Membrane material

The fully imported biogas-specific membrane has flame retardant, antibacterial, and anti-UV properties, and meets the following standards: the sunlight fastness meets the DIN54004 level 7 standard, the flame retardant performance meets the DIN 4102 B1 design standard, and the thermal expansion and contraction resistance meets the DIN53361 standard. , the waterproofness complies with DIN 51635 standards, and the ductility meets DIN 53359 standards.

The outer membrane is coated with PVC/PVDF, which has high strength and high self-cleaning properties; the bottom membrane of the inner membrane has good air tightness and remains inert to the main components of biogas (CH4, H2S). The strength selection of the membrane material generally ranges from 4,000 N/5 cm to 9,000 N/5 cm. The strength of the membrane material can be calculated based on the wind and snow load.

controlling device

The fan is an important part of the double-membrane gas cabinet. Yinghuan uses special anti-corrosion and explosion-proof fans made of FRP to adapt to the harsh on-site environment and ensure the fan's durability.

The gas cabinet storage monitoring device is an important part of the gas cabinet. The biogas storage volume signal can be used for remote control of subsequent biogas user equipment. For example, when the cabinet reaches the 90% high level, the biogas torch will be automatically started; when it is lower than the 20% low level, , giving a low-level alarm, and at the same time shutting down the biogas booster fan, boiler and other gas equipment in a chain.

e27ca1f7a0c270e51750d2d671242f2

COMPANY PROFILE

Shandong Wanze Shengshi Environmental Protection Technology Co., Ltd. is located in the beautiful kite capital of Weifang. It is an environmental protection technology company specializing in environmental engineering and equipment research and development, production, sales, installation, debugging, after-sales service, and providing customers with overall sewage treatment solutions. With a market-oriented approach and high-tech research and development as the leader, the company has successively launched multiple industry-leading technologies in China. Greatly improving the service life of the equipment, reducing operating costs, and expanding the application of the equipment in difficult engineering fields. Our company's products have been widely applied in industries such as sewage treatment plants, hospital wastewater, aquaculture wastewater, industrial circulating cooling water, reclaimed water reuse, harmless treatment of chemical wastewater, food processing, etc., covering anaerobic fermentation biogas engineering for livestock manure, resource treatment engineering for kitchen waste, sewage treatment engineering, biogas desulfurization and purification engineering, organic fertilizer engineering, odor gas treatment engineering, etc. Due to its reasonable design, stable and reliable operation, high degree of automation, and good after-sales service, the product has won widespread praise from users in various industries.

1.Q: Where is your company? How can I visit there?

A:The company is located in Zhongcheng International, Kuiwen District, Weifang City, Shandong Province, China. It is about an hour's drive from Qingdao Airport and Weifang Railway Station. If you need it, we can come and pick you up. Welcome to visit our company.

2.Q:Do you have minimum order quantity request?
A:No minimum order, but it can get a discount if you order a large quantity.

3.Q:Do you have certificates?
  A:Yes,we have ISO,SGS certificate.

4.Q:Can you meet my special requirements for the product?
A:Yes,we have a professional design team.We can provide drawings according to your requirements.

5.Q:How to buy your idea products?
  A:You can provide us your water or waste sources,water or waste quality,flow rate and ground area (connect us for more details) .

6.Q:How to pay?
  A:T/T and L/C are acceptable and T/T will be more appreciated 30% deposit before producing,70% balance before loading by T/T.

7.Q:What is the delivery time ?
A: It depends on order quantities .Generally speaking ,the delivery time will be within 2 to 4 weeks.

8.Q:How to pack the products?
  A:We use standard package .If you have special package requirements ,we will pack as required ,but the fees will be paid by customers.

9.Q:How do you manufacture your equipment?
  A:Our machining technology includes laser 1 plasma cutting ,automatic welding, CNC cutting and bending.

10.Q:How to install after the equipment arriving destination?
   A:We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you. However, the visa fee ,air tickets ,accommodation, wages will be paid by buyers.
